Design, Build & Install Fully Automated Stretch Wrappers

KForce Videos Button.png

Kaufman Engineered Systems offers a complete line of the most durable stretch wrapping equipment available. Our KForce series of stretch wrap systems can be tailored to each customer's specific needs. When uptime efficiency and equipment longevity are what you desire, Kaufman stretch wrappers are the clear choice.

KForce Stretch Wrap Models:

The images below represent how each type of KForce system might be laid out. The actual configuration of each design is customized based on the customer's unique needs. Click any image for additional details about the model shown.

KForce R20 Stretch Wrapper

R20 Stretch Wrapper

R35 Stretch Wrapper

R35 Stretch Wrapper

R35C Corner Board Stretch Wrapper

R35C Corner Board Stretch Wrapper

T20 Turn Table Stretch Wrapper

T20 Turn Table Stretch Wrapper

Superior stretch wrapping through automation, custom designed and built for you.

Kaufman Engineered Systems’ automated stretch wrappers are unrivaled and designed to match your business’s unique automated material handling needs. Our machines get the job done efficiently and effectively, giving your products the highest level of protection possible. Through custom automation, Kaufman wrappers reduce product loss during storage and transit, lower machine costs, and improve productivity. Your fully automated stretch wrapper will be among the most advanced machinery on the market due to the standard high-quality components, with several additional custom options to choose from.

Videos of KForce Stretch Wrap Systems in Action

Kaufman KForceR35 Overhead Stretch Wrapper 22166

K-Force Automatic High Speed Rotary Arm Stretch Wrapper

Automatic Overhead Stretch Wrap Machine

Automatic Strapping and Stretch Wrap System Including Pneumatic Load Lift and Turn

Dual Case Palletizing System with Corner Board Stretch Wrapper

Strapping and Stretch Wrapping for Secure Loads

Video Training.png

Upon exit of the Palletizing System, the finished load needs securement prior to pick-up by warehouse operators. An automatic strapper or also referred to as an automatic bander, applies a 2 x 2, 4 x 4 or other selected band pattern based on customer needs. KES commonly integrates strapping units along with local controls for strap pattern selection, stop, start, manual, auto and diagnostics. In addition, KES manufactures a lift and turn or a strapper shuttle and sequences the load through the strapper.

Upon completion of strapping the palletized load, the finished load is conveyed to an automatic stretch wrapper. Here stretch wrap is applied to the unit to act as a dust cover and final containment to keep containers in place. KES manufactures a variety of stretch wrapper models to accommodate the loads per hour and film size requirements. Two standard models KES installs commonly is The Sxpa-20-100” automatic rotary arm stretch wrapper and The Expa-15-100” automatic rotary table stretch wrapper. The SXPA rotary arm model applies film to the stationary load while the film head is rotated around the unit. This is beneficial and suggested for more unstable palletized loads. The EXPA rotary table stretch wrapper applies wrap while the turntable is rotating the load and the stretch head is located on a fixed tower. The benefits of a rotary table stretch wrapper are reduced footprint for when space is important. Both solutions offer 20” or 30” film size options, selectable wraps patterns, automatic load height detection, and system diagnostics.

After final packaging through the stretchwrapper, Kaufman Engineered Systems will manufacture and supply finished load accumulation based on customer requirements. KES will work with the customer to design, manufacture, program, install and startup the finished end of line discharge conveyor system to provide loads to the warehouse operators.

K-Force Wrapper (2).jpg

Kaufman provides standard features:

  • Allen Bradley AC Powerflex drives
  • 10, 20, or 35 RPM rotation speeds
  • Load height capacity 60", 80" and 100+"
  • 0-300% film pre-stretch capacity
  • 20" film capacity
  • Heavy duty tubular frame construction
  • Allen Bradley electrical and control components
  • Central lubrication
  • VTC (Variable Tension Control)
  • Quick thread powered pre-stretch for easy film loading
  • Automatic load height scanning
KForce Wrapper Head.jpg

Additional machine options:

  • 30" film capacity
  • ALTC (Automatic Load Tension Control) automatically adjusts tension to load stability requirement
  • Film roping
  • Load lifters that permit film to be wrapped underneath the pallet/load
  • Automatic heat tacker for final film tail (heat seals film)
  • Load stabilizing hold down
  • Reversing for system conveyors
  • Wash-down package
  • Slip sheet plow tabs
  • UL 508A listed control panel
  • CUL control panel
  • Cold room and food grade packages available
  • Top protection (poly or corrugate)
  • Corner board protection
  • Equipment installation services

When uptime efficiency and equipment longevity are what you desire, Kaufman stretch wrappers are the right choice for your business.

Today is the day to maximize the efficiency of your material handling needs. Contact our award winning account managers for a free consultation. Call 419-878-9727 or email us at info@KES-USA.com.

Why Companies Choose Kaufman Engineered Systems

Over 75 Years in Business
  • Stability: With over 75 years of serving our customers, Kaufman continues to provide innovative products backed by five-star service.
  • Quality: No one can match our machinery’s superior construction and durability.
  • Dependability: With our 24-hour service support, you can count on Kaufman to be there when you need us most.
  • In-House Design and Manufacturing: Kaufman employs an entire staff of electrical, mechanical, and robotic engineers to design and install the machines that meet your specific needs.
  • Commitment to Excellence: We are customer-focused and recognize that there are no universal automation solutions. Your needs are thoroughly analyzed and reviewed by our engineering staff to find the most efficient, cost-effective solution for your business.
  • Your Turn-Key Provider: From machine fabrication to installation and start-up, Kaufman is there to support you.
  • Improve your Bottom-Line: Whether shaving seconds off cycle time or squeezing space out of your plant layout, we are committed to improving your efficiencies and operating costs.

Kaufman Engineered Systems is a premier integrator for FANUC robotics offering robotic palletizers, stretch wrapping machinery, automated packing machines, food packaging machines, high-speed packaging, and other robotic material handling systems. Kaufman has been your single source manufacturer for complete end-of-line automated packaging since 1947.
